Grid Lines and Levels

Grid lines and levels are useful as reference lines. Nodes can easily be snapped to these lines.

Adding Grid Lines

Grid lines can be added in the table. The table consists of:

• Name - A description of the grid line
• Type - Vertical (grid line) or horizontal (level)
• Coordinate - The x-coordinate (for grid lines) or z-coordinate (for levels)

Using Grid Lines

When grid lines and levels are enabled in the Display Options, they appear as dotted lines in the graphical view.

With Snap Options configured to snap to grid lines, nodes will automatically snap to intersection points when placed near them.

Benefits

• Quick and accurate placement of nodes
• Consistent spacing in regular structures
• Visual reference for the construction layout
